SysTec IT6000E SQC, Weighing Terminal for Statistical Quality Check
- The weighing terminal in a stainless steel housing complies with ingress protection IP69K and is available as a wall-mount/desk-top unit or in a panel-mount version for installation in the door of a control cabinet.
- High resolution and fast signal processing of the SQC terminal permit precise capturing of samples and fast evaluation
- Checkweighing results of samples and batch are indicated with colored marking on the TFT display
- Typical check cycle (check method ‘Individual’):
- Choose production line
- For new product choose one from product file
- Enter batch data
- Capture weight when threshold is exceeded and start checkweighing
- Assign captured weight to tolerance zone, enter in statistics file
- Capture next sample until complete
- Display and optionally print result of sample
- On end of batch display and optionally print result of batch
- Next cycle
- Operator prompting with clearly structured onscreen menus ensures fast and error free operation and minimum training requirements
- The evaluation method can be selected, either compliant to EC regulations for prepackaged goods or pharmacopeia or with freely chosen limits
- Filling quantities can be checked either by weight or by volume
