SysTec IT4000E TRUCK, Weighing Terminal for Truck Scales. Weights and Measures approved.
- The weighing terminal in a stainless steel housing complies with ingress protection IP69K and is available as a wall-mount/desk-top unit or in a panel-mount version for installation in the door of a control cabinet.
- An intelligent program with clear operator prompting ensures fast and error-free operation. Weight and associated data are fully captured and documented on a weigh-ticket.
- The weigh-ticket contains date, time, vehicle registration number, first and second weights and net weight, product number, product name and additional data
- Weights and Measures approved storage of the first weighing, the weighticket is only printed when the truck returns for the second weighing
- Typical weighing cycle
- Select first weighing
- Enter license plate number
- Enter additional data, e.g. product number or operator ID
- Weighing with ticket print and storing of first weight against a 2-digit number
- Select second weighing
- Enter 2-digit number of first weighing
- Weighing of second weight with net weight print
ATEX Version:
Weighing Application: Panatronik
